Chemical Centrifugal Pumps Manufacturer in Mumbai
Application
Type of industries like Chemical, Textile, Fertilizer, Paper & Pulp, Petrochemical, Food processing, Sugar, Starch, Refinery, Powder Plant, Dairy, Pharmaceutical and Bulk Drugs, Oil extraction etc.
Casing
High efficiency volute type. Suction and discharge nozzle as well as the supporting feet are cast integral with the casing.
Impeller
Enclosed type and accurately balanced dynamically. Hydraulically balanced by back vanes and for large impellers by balancing holes.
Shaft
Three shaft units cover complete range of MEC pumps. Made of high tensile steel and accurately ground all over.
Stuffing Box
Available with suitable gland packing. Mechanical seal arrangement available upon request.
MATERIAL OF CONSTRUCTION (M.O.C.) :
Impeller : Cast Iron / SS - 316, Cast Steel / Bronze etc.
Pump Casing : Cast Iron / SS - 316, Cast Steel / Bronze etc.
Shaft / Sleeve : SS - 410 / SS - 316 - 304
Sealing : Mechanical Seal / Gland Packing
RANGE:
Capacity : 400m3/Hr.
Head : Up to 100 Mt.
Tempreture : Up to 350°C
CICP SERIES
Operation Data
Capacity : Up to 350 M3/hr.
Head : Up to 150 Mtr.
Temperature : Up to 250°C.
Discharge Size : 25mm to 100mm.
Pressure : 15kg/cm2.
Speed : Up to 3500 rpm.
M.O.C : C.I, C.S., SS-304/304L, SS316 / 316L Bronze, Alloy-20, CD4MCU Hast alloy B & C, etc.
Application
Paper & Pulp industries.
Food, Sugar, Salt industries.
Organic / Inorganic chemicals, volatile liquids, Corrosive Chemicals, caustic process, effluent, Filter press, slurry application.
Pharmaceautical, Dyes, Textiles, Kerosene, Diesel and other solvents.
ETP. STP & Wast Water Treatment Plant, Fertilizers, Cement & Steel industries.
For Pumping chemicals with solids in suspension polluted liquids.
Hot and Cold water.
CICP SERIES
Operation Data
Capacity : Up to 2000 M3/hr.
Head : Up to 50 Mtr.
Temperature : 30°C to 90°C.
Discharge Size : Up to 600mm.
Pressure : Up to 5.5kg/cm".
Speed : Up to 1500 rpm.
Impellers : Semi open type / Close.
Consistency : 0% to 1.5%.
M.O.C : C.I., C.S. / S.S, 55 304, SS 316, SS 316 L etc.
Stock Pump Refiners Pump Fan pump Centri cleaner pump Back water pump
Chest pump Separator pump etc...
ETP. STP & Wast Water Treatment Plant, Fertilizers, Cement & Steel industries
For Pumping chemicals with solids in suspension polluted liquids widely used for public & civil engineering.
CICP SERIES
Operation Data
Capacity : Up to 180 M3/hr.
Head : Up to 80 Mtr.
Temperature : Up to 350°C.
Discharge Size : 32mm to 80mm.
Pressure : Up to 8kg/cm2.
Speed : Up to 3500 rpm.
Cooling Method : With Air.
M.O.C : Gray Cast Iron, Cast Steel, Alloy Cast Steel
Application
Petro-chemical industries. Oil industries.
Synthetic- fibre Industries. Textile dyeing, Printing Industries.
Plastic and rubber industries. Paper making industries.
Timber processing industries. Sugar industries.
Food industries. Construction industries.
